Embedded RFID & NFC Solutions

RF components
engineers can
actually spec.

Tagnetix designs and manufactures embedded RFID antennas and reader modules backed by real characterization data. Every component is tested, documented, and matched — so your RF integration starts from a known state, not a guess.

View portfolio → Request samples
Portfolio at a glance
Frequency bands HF · LF · UHF
Antenna SKUs 6
Reader modules 3
HF read range ↑ Superior (tested)
Substrate options Rigid · Flex PCB
Origin US-designed
Custom design Available
Tagnetix is the embedded RF product brand of ATRI Solutions — US-based engineering and manufacturing specialists.
HF NFC PCB antenna coil — 13.56 MHz embedded Embedded RFID reader module hardware
HF 13.56 MHz antenna — PCB coil geometry
Embedded reader module — OEM integration
Product portfolio

Antennas & reader modules

Phase 1 — Available now HF 13.56 MHz · Rigid & Flex PCB
TNX-A01
HF Antenna — Standard
Our anchor product and drop-in upgrade for 25×25mm HF antenna applications. Proprietary coil geometry delivers verified superior read range over market standard at the same form factor.
Frequency13.56 MHz
Dimensions25 × 25 mm
Cable length500 mm
ConnectoruFL
SubstrateRigid PCB
↑ Read range tested
TNX-A02
HF Antenna — Compact
Short-cable variant of the TNX-A01. Same superior read range coil geometry in a 100mm cable format for tightly routed board layouts and space-constrained enclosures.
Frequency13.56 MHz
Dimensions25 × 25 mm
Cable length100 mm
ConnectoruFL
SubstrateRigid PCB
↑ Read range tested
TNX-A03
HF Antenna — Flex
Flexible PCB construction enables conformal mounting on curved surfaces, thin consumer devices, and wearable form factors. Full HF 13.56 MHz NFC and ISO 15693 compatibility.
Frequency13.56 MHz
Dimensions25 × 25 mm
Cable length500 mm
ConnectoruFL
SubstrateFlex PCB
Flex PCB
Phase 2 — LF & UHF expansion 125 kHz · 860–960 MHz
TNX-B01
LF Antenna — Standard
125 kHz rigid antenna with high Q-factor coil optimized for access control, animal identification, and industrial asset tracking. Compatible with EM4100, HID Prox, and FDX-B transponders.
Frequency125 kHz
ConnectoruFL
SubstrateRigid PCB
ProtocolsEM4100 · HID · FDX-B
Coming soon
TNX-B02
LF Antenna — Flex
Flexible 125 kHz antenna for body-worn and implant-adjacent designs. Thin substrate, compliant with biocompatible-safe material standards. For wearable access and livestock tracking.
Frequency125 kHz
ConnectoruFL
SubstrateFlex PCB
ProtocolsEM4100 · ATA5577
Flex PCB Coming soon
TNX-C01
UHF Patch Antenna
860–960 MHz embedded patch antenna for RAIN RFID deployments. Optimized radiation pattern for portal, conveyor, and shelf reading. SMA and uFL connector options available.
Frequency860–960 MHz
ConnectorSMA / uFL
ProtocolRAIN RFID / EPC Gen2
SubstrateRigid PCB
Coming soon
Phase 3 — Reader modules Pre-matched to Tagnetix antenna families
TNX-R01
HF Reader Module
Compact embedded HF/NFC reader built around the ST25R3916. Supports ISO 14443 A/B, ISO 15693, and NFC Forum types 1–5. Pre-matched to TNX-A01 and TNX-A02 for zero-tuning integration.
Core ICST25R3916
InterfaceUART / SPI
ProtocolsISO14443 · 15693 · NFC
Matched toTNX-A01 / A02 / A03
In development
TNX-R02
LF Reader Module
Embedded 125 kHz reader for EM4100, HID Prox, and ATA5577 transponders. UART interface, compact footprint. Pre-matched and characterized against TNX-B01 and TNX-B02 antennas.
Core ICEM4100 / ATA5577
InterfaceUART
ProtocolsEM4100 · HID · ATA5577
Matched toTNX-B01 / B02
In development
TNX-R03
UHF Reader Module
High-performance RAIN RFID reader module built on the Impinj R2000. Dense reader mode, GPIO control, multi-tag inventory. Ethernet and USB host interfaces. Pairs with TNX-C01 antenna.
Core ICImpinj R2000
InterfaceEthernet / USB
ProtocolEPC Gen2 / ISO18000-6C
Matched toTNX-C01
In development
Why Tagnetix

Built for engineers who can't afford to guess at RF.

Industrial embedded RFID hardware
Tagnetix — embedded RFID & NFC solutions · Austin, TX
↑
Characterized, not claimed
Every antenna ships with measured read range data, S11 plots, and validated reader IC pairings. Real test data from real hardware — not datasheet theater.
⇄
Matched pairs, not components
Tagnetix reader modules are pre-tuned to our antenna families. Pair a TNX-R01 with a TNX-A01 and the RF system is already characterized. You integrate, not iterate.
✓
Application-proven
Our HF antenna family was developed and validated in a live 3-phase induction charger deployment for commercial food service. Not a lab prototype.
≡
Three frequencies, one supplier
HF for NFC and proximity, LF for access control, UHF for logistics — all from one vendor with consistent documentation, support, and commercial terms.
◎
Volume-ready
Controlled, automated PCBA manufacturing with quoted pricing at 100, 500, and 1000 unit tiers. Predictable lead times — not "contact us for a quote."
∞
Custom-ready
Custom cable lengths, connector types, or form factors handled as small-batch production runs. One conversation — not a 12-week RFQ cycle with a minimum of 10,000 units.
Applications

Where Tagnetix is deployed

Wireless charging & docking
Object identification and device authentication in wireless charging and docking platforms
TNX-A01 / TNX-R01
Access control
125 kHz proximity readers for door entry, time & attendance, and physical security
TNX-B01 / TNX-R02
Logistics & inventory
UHF RAIN RFID for warehouse, conveyor, and retail shelf tracking at scale
TNX-C01 / TNX-R03
Medical & pharma
HF NFC for patient ID, medication authentication, and cold-chain container monitoring
TNX-A03 / TNX-R01
Industrial IoT
Machine-mounted asset tracking, process automation, and tool management
TNX-A01 · B01 · C01
How we compare

Tagnetix vs. standard catalog suppliers

Feature Tagnetix Catalog supplier
HF read range ✓ Superior — measured & documented — Nominal spec only
Matched reader + antenna ✓ Pre-tuned pairs per SKU — No cross-product matching
Test data supplied ✓ S11, read range curves, IC pairing data — Datasheet only
Three frequency bands ✓ HF · LF · UHF from one supplier Often HF only, or fragmented
Small-batch customization ✓ Cable, connector, form factor — MOQ 10,000+ for custom
Volume pricing tiers ✓ 100 / 500 / 1,000 units High MOQ, opaque pricing
Field-validated design ✓ Deployed in CFS induction charger — Lab-only validation
Tagnetix
Embedded RFID & NFC — Characterized. Matched. Ready.
Tagnetix is the embedded RF product brand of
ATRI Solutions · 5900 Balcones Drive #7431
Austin, TX 78731, United States
info@atrisystems.com
Get started

Ready to specify Tagnetix?

Request samples, a datasheet package, or a custom volume quote. We respond within one business day.

Request samples Custom quote
